Mitsubishi MELSEC PLC AJ65BT-64DAI Digital Analog Converter Module

Mitsubishi PLC MELSEC AJ65BT-64DAI Digital Analog Converter Module/ 4 Channel 4-20mA O/P CC Link Module
  • item no.:

    AJ65BT-64DAI
  • Payment:

    T/T
  • Price:

    $550.03
  • product origin:

    Japan
  • min order :

    1
  • shipping port:

    XIAMEN
  • Product Details

Mitsubishi PLC MELSEC AJ65BT-64DAI Digital Analog Converter Module

Product details

PLCs4

 channel current output module, 4-20mA

This remote module is intended to be installed near the control target.

The main advantages are reduced cabling and the capability of acquiring data and operation results of individual machine modules autonomously.

Technical specification
Digital input current: 16-bit signed binary (0 to 4096)
Analogue output current: 4-20mA d.c.
(external load resistance: 0&Omega to 600Ω)
Output range switching: None
Offset/gain setting: Provided
Output short protection: Provided
Max. conversion speed: 1ms/channel
No. of analogue output points: 4 channels/module
No. of occupied stations: 2 stations
(RX/RY: 32 points each, RWr/RWw: 8 words each)
Connectable terminal block: 27-point terminal block (M3.5)
Applicable wire size: 0.75 to 2.00mm2
Internal current consumption: 0.27A (24V d.c.)
No. of I/O modules: Up to 64
Network speed: Up to 10Mbps
Network distance: Up to 1.2km

Features:
  • Up to 64 I/O modules with a maximum of 32 inputs or 32 outputs each can be connected
  • Compact design which is tough and highly shock-resistant
  • Status indicator LEDs for the inputs
  • Modules can be positioned in a horizontal arrangement or one of four orientations on a flat surface.
  • DIN rail or screw mounting



YUGUAN gives you a 2 year warranty on MITSUBISHI  series we sell.

1.If there has any product quality problems within 2 months since the receipt of goods. we will provide a service of return OR Replacement.

2.Shipping cost &repair cost  by us within 1 year warranty.

3.Shipping cost by buyer, repair cost by us within 2 year warranty.
