Mitsubishi Melsec AJ65VBTCU2-16T CC-Link Input/Output Unit
Mitsubishi Melsec AJ65VBTCU2-16TCC-Link Input/Output Unit
item no.:
AJ65BT-R2NPayment:
T/Tproduct origin:
Japanmin order :
1shipping port:
XIAMENProduct details
This remote module is intended to be installed near the control target and is suitable for use in wet environments.
The main advantages are reduced cabling and the capability of acquiring data and operation results of individual machine modules autonomously.
Technical specification |
|
---|---|
No. of inputs: |
2 |
Isolation method: |
Photocoupler |
Rated input voltage: |
24V d.c. |
Rated input current: |
Approx. 7mA |
Operating voltage range: |
19.2 to 28.8V d.c. (ripple ratio: 5% or less) |
ON voltage/ON current: |
14V/3.5mA or higher |
OFF voltage/OFF current: |
6V/1.7mA or lower |
Input resistance: |
Approx. 3.3kΩ |
Response time: |
|
OFF—ON: |
10ms or lower |
ON—OFF: |
10ms or lower |
Wiring method for common: |
2 points/common (COM1) Positive negative common shared type |
External connection system: |
7-point terminal block (M3.5 screw) |
Network speed: |
Up to 10Mbps |
Network distance: | Up to 1.2km |
