Mitsubishi Melsec AJ65VBTCU2-16T CC-Link Input/Output Unit
Mitsubishi Melsec AJ65VBTCU2-16TCC-Link Input/Output Unit
item no.:
AJ65BT-D62DPayment:
T/Tproduct origin:
Japanmin order :
1shipping port:
XIAMEN
Part Number: AJ65BT-D62D
Configured Specifications
Classification Differential Input Number of Channels(ch) 2
Count input signal level EIA standard RS-422-A differential type line driver level (equivalent to AM26LS31 (Texas Instruments Japan Limited)) Preset External Input DC5/12/24 V 2 to 5 mA
Computing Speed (1 Phase Input) HIGH side: 400kpps/Low side: 10kpps Computing Speed (2 Phase Input) HIGH side: 300kpps/Low side: 7kpps
Note Differential Input - Preset DC Input - Conforming Standards: UL/cUL CE (EMC) RoHS 6
| Ambient Operating Temperature | 0 to 55℃ | ||
|---|---|---|---|
| Ambient Storage Temperature | -20 to 75℃ | ||
| Ambient Operating Humidity | 10 to 90% RH, no condensation | ||
| Ambient Storage Humidity | 10 to 90% RH, no condensation | ||
| Vibration Resistance | JIS B 3502, IEC 61131-2 Compliant | Under Intermittent Vibration |
Frequency: 5 to 8.4 Hz, single amplitude: 3.5 mm Frequency: 8.4 to 150 Hz, constant acceleration: 9.8 m/s2 Sweeps: 10 sweeps in each direction of X, Y and Z |
| Under Continuous Vibration |
Frequency: 5 to 8.4 Hz, Single amplitude: 1.75 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 4.9 m/s2 |
||
| Impact Resistance |
JIS B 3502, IEC 61131-2 compliant (147 m/s2, 3 times in each direction of X, Y and Z) |
||
| Operating Atmosphere | No corrosive gas | ||
| Operating Altitude | 0 to 2,000 m | ||
| Installation Location | Inside the control panel | ||
| Overvoltage Category | II or lower | ||
| Pollution Degree | 2 or less | ||
YUGUAN gives you a 2 year warranty on MITSUBISHI series we sell.
1.If there has any product quality problems within 2 months since the receipt of goods. we will provide a service of return OR Replacement.
2.Shipping cost &repair cost by us within 1 year warranty.
3.Shipping cost by buyer, repair cost by us within 2 year warranty.
Email me: Sales@plcdealer.com
sales-lin@plcdealer.com
WhatsApp:+8615917993180
Phone: +86 13799737824/+86 15917993180
THANK YOU SO MUCH!
